-38%

Cooler Master Vertical Graphics Card Holder Kit V3 For E-ATX Cabinet (White)


4,999.00 7,999.00

Cooler Master Vertical Graphics Card Holder Kit V3 comes with white color design and fit in ATX chassis. A PCIe 4.0 riser cable is included to assist the installation process and ensure high efficiency at uncompromised speeds

Features:

Supporting cases ranging in size from m-ATX to ATX, and featuring a removable adjustable GPU bracket, this remastered design allows unprecedented compatibility with various builds and setups. A PCIe 4.0 riser cable is included to assist the installation process and ensure high efficiency at uncompromised speeds.

Effortlessly Showcase Your Graphics Card

Bring the best out of your components by showing off your GPU.

Installation in a m-ATX Case

When installing the Vertical GPU Holder Kit V3 in a m-ATX case users may need to remove the rear case fan for additional clearance.

It is also necessary to use low profiles CPU air-coolers, all-in-one liquid coolers, or custom water cooling loops to guarantee optimal clearances between components.

Compatible with all Standard ATX Chassis

The newly revised Vertical Graphics Card Holder Kit fits all standard ATX chassis, now providing even more options for adjusting graphics card position.

X Axis Adjustability

Toollessly adjustable up to 65mm horizontally…

Z Axis Adjustability

…as well as up to 30mm towards the side panel.

Intuitive Installation Process

The modular design allows GPUs to placed in the system after the holder has been fixed in a preferred layout.

Specifications:

 Model Number MCA-U000R-WFVK03
 Color  White
 Dimensions (L x W x H)  GFX Holder kit: 249 x 148.1 x 141.8 mm (close size), GFX Holder kit: 305 x 178.1 x 141.8 mm (open size), Riser cable: 165mm (6.49in)
 Supported Chassis Type  E-ATX, ATX, Micro ATX (may interfere with component installation on the rear panel. Max. CPU cooler height limited to 70mm.)
 Supported Graphics Cards  Any length, up to 3 slots wide
 Riser Cable Model  Riser Cable PCIe 4.0 x16
 Compatibility  PCIe 4.0 and older
 CE Certifications Number  BKC210933AC
 PCB / Wire UL Numbers  E1895721 / E252840
 Component Materials  PCBA, Silver Plated Copper Wire 30 AWG
 Insulation Materials  PE, TPE
 Other Materials  ABS, PP, SGCC Steel, Nickel, Gold, Brass
 Connectors  PCIe x16 Male to PCIe x16 90° Female
 Rated Working Voltage and Current  DC 12V / 5A
 Operating Temperature  -20° to +100° Celsius
 Required PCI slots  Minimum 4 PCI slots required for mounting
 Weight  0.81 kg
 Warranty  2 Years
Note *** Features, Price, Specifications are subject to change without notice.
