-55%
,

AMD Ryzen 9 7950X Processor With Radeon Graphics


49,999.00 111,000.00

Specification

General Specifications
Platform Desktop
Market Segment Enthusiast Desktop
Product Family AMD Ryzen™ Processors
Product Line AMD Ryzen™ 9 Desktop Processors
AMD PRO Technologies No
Consumer Use Yes
Regional Availability Global
Former Codename “Raphael AM5”
Architecture “Zen 4”
# of CPU Cores 16
Multithreading (SMT) Yes
# of Threads 32
Max. Boost Clock Up to 5.7GHz
Base Clock 4.5GHz
L1 Cache 1MB
L2 Cache 16MB
L3 Cache 64MB
Default TDP 170W
Processor Technology for CPU Cores TSMC 5nm FinFET
Processor Technology for I/O Die TSMC 6nm FinFET
CPU Compute Die (CCD) Size 71mm²
I/O Die (IOD) Size 122mm²
Package Die Count 3
Unlocked for Overclocking Yes
AMD EXPO™ Memory Overclocking Technology Yes
Precision Boost Overdrive Yes
Curve Optimizer Voltage Offsets Yes
AMD Ryzen™ Master Support Yes
CPU Socket AM5
Supporting Chipsets
  • X670E
  • X670
  • B650E
  • B650
CPU Boost Technology Precision Boost 2
Instruction Set x86-64
Supported Extensions AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB) Not included
Max. Operating Temperature (Tjmax) 95°C
*OS Support
  • Windows 11 – 64-Bit Edition
  • Windows 10 – 64-Bit Edition
  • RHEL x86 64-Bit
  • Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C® Support Yes
Native USB 3.2 Gen 2 (10Gbps) Ports Ports 4
Native USB 3.2 Gen 1 (5Gbps) Ports 0
Native USB 2.0 (480Mbps) Ports 1
Native SATA Ports 0
Native PCIe® Lanes (Total/Usable) 28/24
Additional Usable PCIe Lanes from Motherboard
  • AMD X670E  12x Gen4
  • AMD X670  12x Gen4
  • AMD B650E  8x Gen4
  • AMD B650  8x Gen4
NVMe Support Boot, RAID0, RAID1, RAID10
Memory Channels 2
Max. Memory 128GB
System Memory Subtype UDIMM
Max Memory Speed
  • 1x1R 5200 MT/s
  • 1x2R 5200 MT/s
  • 2x1R 3600 MT/s
  • 2x2R 3600 MT/s
ECC Support Yes (Requires mobo support)
Graphics Capabilities
Integrated Graphics Yes
Graphics Model AMD Radeon™ Graphics
Graphics Core Count 2
Graphics Frequency 2200 MHz
GPU Base 400 MHz
USB Type-C® DisplayPort™ Alternate Mode Yes
Product IDs
Product ID Boxed 100-100000514WOF
Key Features
Supported Technologies
  • AMD EXPO™ Technology
  • AMD Ryzen™ Technologies
Warrenty; 3 Years
Note *** Features, Price, Specifications are subject to change without notice.
  • Series Ryzen 9
  • CORES 16 Cores
  • THREADS 32 Threads
  • SPEED 4.5GHz
  • SPEED (TURBO)5.7GHz
  • CACHE80 MB
  • MAX MEMORY SUPPORT128 GB
  • INTEGRATED GRAPHICS Radeon Graphics
  • INCLUDED CPU COOLER No
  • UNLOCKED Yes
  • TDP170W
  • WARRANTY*3 Years
SKU: 100-100000514WOF Categories: , Tags: , ,
